HILAND series
The Formbuilder HILAND Series supports industrial 3D digitization for inspection, reverse engineering and product development.
Technical Specifications
Model Hiland 500
Scanning Mode Quick scanning, Large area scanning, Deep-hole scanning, Fine scanning
Light Source 26 beam crossed laser lines + 7 fine scanning parallel lines + single laser line
Scanning Accuracy 0.02mm
Scanning Speed 4.660,000 measurements/second
Scanning Range 750mmx650mm
Scanning Method Laser scanning (safe laser)
Laser Type classl(Eye-safe)
Maximum SamplingPoints Distance 0.02mm
Resolution 5M x 2
Volume Accuracy 0.020mm+0.012mm/m
Baseline Distance 300 mm
Depth Of Field 800 mm
Transmission Method USB 3.1x2 dual transmission, further supports USB3.2 Gen2
Photogrammetry Contains VPG video stream, contactless photogrammetry
Operating Temperature 0℃-40℃(Non-cold temperature)
Output Data .ply,.obj,.vtk,.stl,.off,.ma,.txt,.asc,.neu,.xyz,scv,.pn,.pv,.pov and support customized format
Industrial Applications
Discuss Your HILAND Application
Manual Download
The HILAND Series is developed and manufactured by Hangzhou BlackboxCV Co., Ltd. for Formbuilder’s international product portfolio.
